A few months ago (July 2025) I wrote an article on how to set up the new, but still in preview High Volume Email (HVE) service in Microsoft 365/Exchange Online.
I’ve been using it for a while now, so here are the issues I have found. Hopefully these get resolved before the product goes into general release, as all these issues are not issues with the generic SMTP endpoint in Office 365 that HVE is designed to replace.
1. Ciphers
The HVE endpoint is smtp-hve.office365.com and is completely separate infrastructure than the legacy auth based smtp.office365.com endpoint. Microsoft list online the ciphers that TLS supports in Office 365, and I have found that HVE does not support the same list. Therefore you can have a scan or print to email device that can connect to smtp.office365.com but not to smtp-hve.office365.com
2. Timeouts
The HVE endpoint TCP connection times out at one minute. The legacy endpoint times out at five minutes. This means that any action that takes longer than 60 seconds to complete on the HVE endpoint will result in a disconnection. I have an example where I can scan a single page to email but not multiple pages! This worked on the legacy smtp.office365.com endpoint.
Of course this is likely an issue with my hardware, in that it probably opens a connection and then scans the document page(s) and then send the scan as an email to HVE. If the scanning takes more than one minute the connection closes. Ideally the device should scan, open the connection and send, but it does not and this means that this legacy printer only works (currently) with the legacy endpoint and not HVE. The legacy endpoint is being turned off in nine months, so there is work to be done by Microsoft on this.
3. Email Size
This is covered in step 4, as this is where I discovered it, but it’s important enough to have its own entry on this list. HVE allows a max email size of 10MB but the legacy endpoint allows for 150MB.
Sure, the recipient mailbox might have a lower size limit and the email not arrive, but it should not be configured that the service itself is not able to do at least the default email size of Office 365 which is 35MB.
4. SMTP Commands
Connecting to the legacy endpoint and starting an Enhanced SMTP session (EHLO devicename) returns a number of supported SMTP features. Doing the same on the HVE endpoint returns considerably less.
I have covered message SIZE in the above item as it was worth calling out on its own, but here are the other SMTP protocol commands supported (or not):
smtp.office365.com
220 servername.outlook.office365.com Microsoft ESMTP MAIL Service ready at Tue, 2 Sep 2025 11:37:09 +0000 []
EHLO testdevice
250-servername.outlook.office365.com Hello [w.x.y.z]
250-SIZE 157286400
250-PIPELINING
250-DSN
250-ENHANCEDSTATUSCODES
250-STARTTLS
250-8BITMIME
250-BINARYMIME
250-CHUNKING
250 SMTPUTF8
smtp-hve.office365.com
220 ic3-transport-smtp-lob-deployment-id-id Microsoft ESMTP MAIL Service ready at Tue, 2 Sep 2025 11:39:28 +0000 ()
EHLO testhvedevice
250-ic3-transport-smtp-lob-deployment-id-id Hello [w.x.y.z]
250-SIZE 10485760
250-STARTTLS
250 CHUNKING
So, what can we work out from this? Firstly, any errors are not going to include enhanced status codes. This might not be an issue, but an email getting returned with “550” is not as good as getting “550 5.1.10”. 550 means “server error”, but 550 5.1.10 means “server error – recipient was not found”.
Next, the lack of support for SMTPUTF8 means the messages only support ASCII characters and not unicode. Specifically this is Email Address Internationalization (EAI) support as defined in RFC 6531, 6532 and 6533. So anything the printer adds to the message in unicode is possibly unreadable.
There are other features not supported, such as the two MIME options, but these are less likely to be an issue – though if your printer requires them and they work with the legacy endpoint we should expect them to work with the HVE endpoint as well and they will not. 8BITMIME means SMTP supports 8-bits ASCII but HVE only claims to support 7-bit ASCII. BINARYMIME supports a more efficient way to send binary data (i.e. a scan from a printer) to the SMTP server endpoint.
5. Bounces
Any error in HVE for email delivery is likely to be sent back to the sender. But the sender is an account without a mailbox, and so no-one can login and look for errors in email flow. With the legacy endpoint you could assign an Exchange Online licence to the account and create a shared mailbox that would hold any responses from the SMTP endpoint (i.e. the 550 5.1.10 mentioned above). But this is not possible for HVE as you should not licence these accounts and give them a mailbox.
So HVE should have the option to provide a bounce address that any error is copied to in addition to being returned to the sender. Now its possible to create bounces@defaultdomain account and any bounce to a non-existent address ends up here, but this is for everything and not specific to HVE. And of course, the HVE account exists, so the bounces mailbox might ignore these messages!
6. Azure Communication Services
This is not High Volume Email, or is it! It is an option to use when replacing the legacy SMTP endpoint (HVE or ACS), and connecting to the ACS SMTP endpoint shows a number of similarities to HVE and some differences. So for completion for this article, here is what you might get or not get if you use Azure Communication Services for high volume email instead of the HVE endpoint:
220 ic3-transport-smtp-acs-deployment-id-id Microsoft ESMTP MAIL Service ready at Tue, 2 Sep 2025 11:54:55 +0000 ()
EHLO azurecommdevice 250-ic3-transport-smtp-acs-deployment-id-id Hello [w.x.y.z]
250-SIZE 31457280
250-STARTTLS
250 CHUNKING
The HVE endpoint looks very similar to the ACS endpoint from a server name perspective (“acs” instead of “lob” in the name). But the ACS endpoint supports a message size of 30MB. The ciphers are likely to be different from Microsoft 365 as well, as this is an Azure endpoint and not an M365 endpoint.
